NANO N6 Thermal Imaging Clip-on
Designed for a pre-zeroed experience, NANO transitions seamlessly to thermal imaging with zeroed day scopes while adding minimal bulk at under 100 mm long.
Product highlights
Sensor Resolution
NETD
Base Magnification
Compact Design
Built-in Rangefinder
Ballistic Calculation
Free Shipping
5-Year Warranty with Product Registration
60-Day Hassle-Free Returns
Accessories
WHY CHOOSE NANO?
NANO is an ultra-compact thermal clip-on designed for a pre-zeroed experience. Engineered for precise optical alignment with properly zeroed day scopes, it enables a seamless transition to thermal imaging.
At less than 100 mm in length, NANO adds minimal bulk to your setup while remaining easy to carry. A thermal sensor with a NETD≤15mK delivers exceptional image clarity and enhanced detail recognition. Powered by a replaceable 18650 battery, NANO enables quick battery swaps for uninterrupted operation in the field, while the versatile 2-in-1 design allows use as both a clip-on and a monocular.
No Re-Zeroing. Precise Accuracy.
Better Balance. Better Control.
Less Length. More Stability.
With a sub-100 mm design, NANO adds minimal length to your setup. Compared with longer clip-ons, its compact form helps reduce the impact of front-end weight and length, contributing to improved balance and a more stable operating experience.
Less Weight. Less Impact.
At just 435g, NANO minimizes the impact of added front-end weight on your day scope, helping support consistent accuracy while remaining comfortable for extended field use.
Sharper Image. Smoother Viewing.
Capture More Thermal Detail
A multi-lens germanium optical system with advanced coatings helps maximize infrared transmission, delivering richer image detail and improved target definition.
Lower Downtime. Lower Cost.
Adaptive Clip-on Compatibility
NANO features four selectable UI scaling levels when operating as a clip-on, allowing the display to better match different day scope magnifications. The centrally located focus lever enables intuitive operation from either side.
Quick Monocular Conversion
With a dedicated eyepiece attachment, NANO can be quickly converted into a handheld thermal monocular for flexible standalone observation in the field. Its compact and lightweight eyepiece is easy to carry, store, and integrate into your hunting kit.
Technical Specs
Sensor Specs
Type
VOx Uncooled
Resolution
640×512
Pixel Pitch
12μm
NETD
≤15mK
Frame Rate
50Hz
Optical Specs
Objective Lens
50mm, F1.0
Base Magnification
1×
Field of View(H×V), degrees/m@100m
8.8°×6.6°/15.4m×11.5m
Digital Zoom of monocular mode
3～12× (4x)
Recommended magnification of Daylight Optics
1-16x
Eye Relief
20mm
Exit pupil
35mm
Detection Range
2597m
Display Specs
Type
OLED
Resolution, pixels
1920×1080
Laser Rangefinding
Measurement Range
1500m
Measurement Accuracy
±1m
Video Recorder
Video / Photo Resolution
1408×1080
Video / Photo Format
.mp4 / .jpg
Built-in Memory
64 GB
Physical Specs
Degree of Protection, IP Code
IP67
Operating Temperature Range
-20℃ to +50℃
Weight
435 g
Dimensions
99.8×90.8×70.2 mm
Connections and Compatibilities
Battery Type
18650(70 mm length)
Operating Time on Battery Pack (at t=25℃/72°F)
4h
External Power Supply, V
3.6V（Battery）/5V(Type-C USB)
Included in the Box
NANO N6
Remote Control × 1
18650 Battery × 2
Battery Charger × 1
USB Type C Cable × 1
Lens Cloth × 1
Thermal Target × 10
Wrench × 1
Battery fireproof bag × 1
Protable bag × 1
Downloads
NANO User Manual
